Magic Series Modular Dryer
Contact Now
Product Parameters
Magic Series Modular Desiccant Dryer consists of extruded aluminum columns which filled with high performance desiccant, drying the compressed air to ISO8573.1 international standard.
One column is operational drying, while another column is regenerating.
Magic Series Modular construction eliminates the need for complex valves, huge towers and interconnecting piping which are used in conventional tower dryers.
High Quality Air
Clean,dry compressed air supply in accordance with ISO8573.1:2001 class 3.2.1
Reliable Performance
High quality desiccant ensures stable dew point performance
Energy Efficient
With Dew Point Operation System (DPOS)(optional), Magic Modular Dryer provides maximum energy saving
Smart Control
Equipped with PLC touch screen as standard configuration
Space Saving
Advance aluminium extruded column replacing traditional twin tower dryers, taking up less floor space and making installation easily
Product selection
| Model | Nominal flow rate (m²/min) | connection | Dimensions (mm) | Weight(Kg) | ||||
| -20°C -40°C -70°C | H W D | |||||||
| PMD104* | 1.3 | 1.2 | 0.8 | 1” | 745 | 425 | 285 | 39 |
| PMD106* | 2.2 | 2 | 1.4 | 1” | 945 | 425 | 285 | 51 |
| PMD108* | 2.9 | 2.6 | 1.8 | 1” | 1145 | 425 | 285 | 64 |
| PMD110* | 3.7 | 3.4 | 2.4 | 1” | 1345 | 425 | 285 | 77 |
| PMD112* | 4.4 | 4 | 2.8 | 1” | 1545 | 425 | 285 | 89 |
| PMD115* | 5.6 | 5.1 | 3.6 | 1” | 1845 | 425 | 285 | 108 |
| PMD116* | 5.9 | 5.4 | 3.8 | 1” | 1945 | 425 | 285 | 115 |
| PMD210* | 7.4 | 6.7 | 4.7 | 2” | 1390 | 400 | 630 | 165 |
| PMD212* | 8.9 | 8.1 | 5.7 | 2” | 1590 | 400 | 630 | 190 |
| PMD215* | 12.5 | 11.4 | 8 | 2” | 1890 | 400 | 630 | 228 |
| PMD315* | 17.5 | 15.9 | 11.2 | 2” | 1890 | 400 | 795 | 323 |
| PMD415* | 23.4 | 21.3 | 14.9 | 2-1/2” | 1890 | 400 | 960 | 418 |
| PMD515* | 28.8 | 26.2 | 18.4 | 2-1/2” | 1890 | 400 | 1125 | 513 |
| PMD615* | 34.6 | 31.5 | 22.1 | 2-1/2” | 1890 | 400 | 1293 | 608 |
| PMD715* | / | 35.8 | 25.6 | 2-1/2” | 1890 | 400 | 1460 | 703 |
| PMD815* | / | / | 29.7 | 2-1/2” | 1890 | 400 | 1625 | 798 |
Technique info
Correction factor for inlet air temperature CFT
| ℃ | 25℃ | 30℃ | 35℃ | 40℃ | 45℃ | 50℃ |
| CFT | 1 | 1 | 1 | 0.97 | 0.88 | 0.73 |
Correction factor for inlet pressure CFP
| Bar | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 16 |
| CFP | 0.63 | 0.75 | 0.88 | 1 | 1.13 | 1.25 | 1.38 | 1.5 | 1.63 | 1.75 | 1.88 | 32.1 |
Correction factor for dew point CFD
| PDP | -20 | -40 | -70 |
| CFD | 1.1 | 1 | 0.7 |
Calculate the dryer capacity: Actual inlet flow rate=Selected flow rate x CFT x CFP x CFD
